APPLICATION EXAMPLE
Upper room UV germicidal irradiation with LEDs and VIOLET-12X1-O
For help with an application simulation using our optics, or to make a request about what application you want us to cover next, contact Tech support
UR-UVGI(-LED)
Upper room ultraviolet germicidal irradiation (with light-emitting diodes) + LEDiL VIOLET
Downlight luminaire under VIOLET is 40 cm wide, and VIOLET lens surface is around 15 cm from the edge.
Typically considered eye-safe value for 8 hour exposure: 0.3uW/cm2
Source: https://www.ncbi.nlm.nih.gov/pmc/articles/PMC2099326/
SETUP:
| Application: | UR-UVGI(-LED) |
| Optics: | VIOLET-12X1-O |
| Optics efficiency: | 71 % |
| LED: | 7070 package size UVC LED (280 nm) |
| Total UV-C output/VIOLET-O: | 526 mW |
| Total power/12 LEDs: | 24 W |
| VIOLET installation height: | 2.9 m |
| Tilt: | 5° upwards |
| Room size: | 8 x 10 x 3.5 m |
| Surface reflectance: | 10 % |
RESULTS:
| UPPER AIR (3.1 m): | Max: 70.2 µW/cm² |
| EYE LEVEL (1.7 m): | Max: 0.3 µW/cm² |
Upper room UV germicidal irradiation with LEDs and VIOLET-12X1-O
For help with an application simulation using our optics, or to make a request about what application you want us to cover next, contact Tech support
