Application example
STRADA-2X3-5050-T2 | MH & pole distance calculations
For help with an application simulation using our optics, or to make a request about what application you want us to cover next, contact Tech support
See how the C3 and M3 street lighting requirements can be met with different mounting height and pole distance setups in the table above.
Setups vary in LED lumens, boom angle and overhang. For more specific results please consult LEDiL Tech support.
Setup:
| Optics: | STRADA-2X3-5050-T2 |
| Number of lanes: | 2 pcs |
| Road width: | 7 m |
| Overhang: | -0.5 - 2.0 m |
| Boom angle: | 0°, 5° or 10° |
STRADA-2X3-5050-T2 | MH & pole distance calculations
For help with an application simulation using our optics, or to make a request about what application you want us to cover next, contact Tech support
