Luminaire example
Downlight luminaires with DAISY-7X1-CRV
For help with an application simulation using our optics, or to make a request about what application you want us to cover next, contact Tech support
Luminaire example #1
| Optics: | DAISY-7X1-CRV, DAISY-7X1 |
| Number of optics: | 8 |
| Luminaire size: | 600/680 x 400 mm |
| LED: | 2835 Mid-power |
| LEDs/each optical element: | 2 |
| Luminous flux (luminaire): | 3600 lm (37.5 lm/LED) |
Luminaire example #2
| Optics: | DAISY-7X1-CRV |
| Number of optics: | 3 |
| Luminaire size: | 600 x 200 mm |
| LED: | 2835 Mid-power |
| LEDs/each optical element: | 4 |
| Luminous flux (luminaire): | 2700 lm (37.5 lm/LED) |
Luminaire example #3
| Optics: | DAISY-7X1-CRV |
| Number of optics: | 4 |
| Luminaire size: | 400 x 400 mm |
| LED: | 2835 Mid-power |
| LEDs/each optical element: | 4 |
| Luminous flux (luminaire): | 3600 lm (37.5 lm/LED) |
Downlight luminaires with DAISY-7X1-CRV
For help with an application simulation using our optics, or to make a request about what application you want us to cover next, contact Tech support
The information contained herein is the property of LEDiL Oy, Joensuunkatu 13, FI-24100 SALO, Finland and is subject to change without notice. Please visit www.ledil.com for additional information, such as the latest photometric files, 3D mechanical models, and application notes relating to handling, gluing and taping.
